The Effect of Alkalization Process on The Mechanical Properties of Straw Biocomposites as Egg Tray Materials

##plugins.themes.academic_pro.article.sidebar##

Published Oct 30, 2026
https://doi.org/10.55043/jfpc.v5i3.690
Download
PDF
Statistic

Downloads

Download data is not yet available.
Vol. 5 No. 3 (2026): Journal of Fibers and Polymer Composites

##plugins.themes.academic_pro.article.main##

Achmad Mawahib
University of Jember
Robertoes Koekoeh Koentjoro Wibowo
University of Jember
Imam Sholahuddin
University of Jember
Mochamad Asrofi
University of Jember
Andi Sanata
University of Jember
Salahuddin Junus
University of Jember
Danang Yudistiro
University of Jember

Abstract

Rice plants constitute the majority of crops grown by farmers in Indonesia. Straw is a harvest from rice plants which is still underutilized. The majority of farmers burn this straw waste to destroy it. This creates serious problems and can pollute the environment. One alternative for utilizing waste from straw is to make a biocomposite product in the form of egg tray molds from rice straw. One material that can be used as an alternative is cassava starch because it can decompose naturally. In this study, biocomposite material was made from cassava starch reinforced with rice straw which had been alkalized with varying concentrations of NaOH (7, 8, and 9%), boiling time (30, 45, and 60 minutes), and boiling temperature (70-80, 80 -90, and 90-100°C) and uses the casting method in the manufacturing process. The tests carried out are tensile testing and biodegradable testing. Tensile testing was carried out to determine tensile strength, strain and tensile modulus using ASTM D638 Type IV. Biodegradable testing was carried out to determine the level of natural degradation of biocomposites using ASTM D6868. The highest tensile test results were shown with the A3 specimen with variations in the alkalization process of 9% NaOH, 45 minutes, and 70-80°C. This specimen produces a tensile stress of 9.23 MPa, a strain of 14.82%, and an elastic modulus of 62.28 MPa. The results of the degradation test showed that specimen t1 with variations in alkalization of 8% NaOH concentration, 30 minutes, and 80-90°C with a degradation rate of 3.7%/day. These findings demonstrate that alkalization significantly improves the mechanical integrity and biodegradability of rice straw biocomposites, highlighting their potential as eco-friendly alternative materials for bio-based packaging applications, such as molded pulp or egg tray packaging.

##plugins.themes.academic_pro.article.details##

Creative Commons License

This work is licensed under a Creative Commons Attribution-NonCommercial-ShareAlike 4.0 International License.

Author Biographies

Achmad Mawahib, University of Jember

Department of Mechanical Engineering, Faculty of Engineering, University of Jember, Jember, Indonesia

Robertoes Koekoeh Koentjoro Wibowo, University of Jember

Department of Mechanical Engineering, Faculty of Engineering, University of Jember, Jember, Indonesia

Imam Sholahuddin, University of Jember

Department of Mechanical Engineering, Faculty of Engineering, University of Jember, Jember, Indonesia

Mochamad Asrofi, University of Jember

Department of Mechanical Engineering, Faculty of Engineering, University of Jember, Jember, Indonesia

Andi Sanata, University of Jember

Department of Mechanical Engineering, Faculty of Engineering, University of Jember, Jember, Indonesia

Salahuddin Junus, University of Jember

Department of Mechanical Engineering, Faculty of Engineering, University of Jember, Jember, Indonesia

Danang Yudistiro, University of Jember

Department of Mechanical Engineering, Faculty of Engineering, University of Jember, Jember, Indonesia

How to Cite
Mawahib, A., Wibowo, R. K. K., Sholahuddin, I., Asrofi, M., Sanata, A., Junus, S., & Yudistiro, D. (2026). The Effect of Alkalization Process on The Mechanical Properties of Straw Biocomposites as Egg Tray Materials. Journal of Fibers and Polymer Composites, 5(3), 252–262. https://doi.org/10.55043/jfpc.v5i3.690

References

  1. Harini R, Ramadhan C, Rudi FS. Agricultural resource potential for improving food security and community welfare in Penimbun Village, Karanggayam, Kebumen, Central Java. IOP Conference Series: Earth and Environmental Science 2020:451:012041. https://doi.org/10.1088/1755-1315/451/1/012041.
  2. Parshad J, Kumar R, Chhokar V, Patil N, Beniwal V, Singh N, et al. Rice residue management: Alternative strategies and emerging technologies for a sustainable ecosystem. Pedosphere 2025;35:53–66. https://doi.org/10.1016/j.pedsph.2024.06.004.
  3. Winarno K, Sustiyo J, Aziz AA, Permani R. Unlocking agricultural mechanisation potential in Indonesia : Barriers , drivers , and pathways for sustainable agri-food systems. Agric Syst 2025;226:104305. https://doi.org/10.1016/j.agsy.2025.104305.
  4. Wibowo RKK, Sumarji, Robbani HN. The effect of mass fraction of rice straw fiber on the mechanical properties and water absorption of cassava starch biocomposite. Int J Integr Eng 2025;17:78–89. https://doi.org/10.30880/ijie.2025.17.04.007.
  5. Czechowski L, Fudalej GK, Szewczyk W. The Strength of Egg Trays Under Compression: A Numerical and Experimental Study. Materials (Basel) 2020;13:2279. https://doi.org/10.3390/ma13102279.
  6. Cabrera-villamizar LA, Ebrahimi M, Martínez-Abad A, Talens- Perales D, Lopez- Rubio A, Fabra MJ. Order Matters: Methods for Extracting Cellulose from Rice Straw by Coupling Alkaline, Ozone and Enzymatic Treatments. Carbohydr Polym 2024;328. https://doi.org/10.1016/j.carbpol.2023.121746.
  7. Raudhatussyarifah R, Sediawan WB, Azis MM, Hariati I. Microcrystalline Cellulose Production by Acid Hydrolysis of Hydrotropic Rice Straw Pulp. Int. Bioprocess. Assoc Subj Conf 2022;963:012055. https://doi.org/10.1088/1755-1315/963/1/012055.
  8. Pramudia M, Umami MK, Prasetyo T, Roziqin F. The influence of sodium hydroxide ( NaOH) solution concentration on tensile strength of corn husk fiber-epoxy resin composite. Journal of Physics: Conference Series 2025;2972:012050. https://doi.org/10.1088/1742-6596/2972/1/012050.
  9. Nguyen C Van, Mangat PS. Properties of rice straw reinforced alkali activated cementitious composites. Constr Build Mater 2020;261:120536. https://doi.org/10.1016/j.conbuildmat.2020.120536.
  10. Vo N, Nguyen CTX, Le TM, Pham CD, Do NHN, Le KA, et al. Recovery of rice straw cellulose on pilot scale for fabrication of aerogel for oil / water separation. Chem Eng 2022;97:73–8. https://doi.org/10.3303/CET2297013.
  11. Xuehua C, Xindong XU, Qing W, Pengxiang QI, Shan C. Progress in research on cassava starch-based film materials. Food Sci 2021;42:254–263. https://doi.org/10.7506/spkx1002-6630-20200404-049. https://www.sciengine.com/FoodScience/doi/10.7506/spkx1002-6630-20200404-049
  12. Jumaidin R, Gazari AS, Kamaruddin ZH, Kamaruddin ZH, Zakaria NH, Kudus SIA, et al. Mechanical properties of thermoplastic cassava starch / coconut fibre composites : Effect of fibre size. Pertanika Journal of Science & Technology 2024;32:91–113. https://doi.org/10.47836/pjst.32.S2.07. https://www.researchgate.net/publication/381428841_Mechanical_Properties_of_Thermoplastic_Cassava_StarchCoconut_Fibre_Composites_Effect_of_Fibre_Size
  13. Shang X, Yang J, Song Q, Wang L. Efficacy of modified rice straw fibre on properties of cementitious composites. J Clean Prod 2020;276:124184. https://doi.org/10.1016/j.jclepro.2020.124184.
  14. ASTM International. Standard Test Method for Tensile Properties of Plastics. Am. Soc. Test. Mater., New York: 2015, p. 1–17. https://doi.org/10.1520/D0638-14.1. https://store.astm.org/d0638-22.html
  15. Xiao L, Liu X, Jing-yao LI. Effect of alkali treatment of straw fiber on mechanical properties of alkali slag cement composites. IOP Conference Series: Earth and Environmental Science 2019;267:022028. https://doi.org/10.1088/1755-1315/267/2/022028.
  16. Adekomaya O, Adama K. Glass-fibre reinforced composites: The effect of fibre loading and orientation on tensile and impact strength. Niger J Technol 2017;36:782–7. https://doi.org/10.4314/njt.v36i3.17.
  17. Fajar RM, Asrofi M, Djumhariyanto D, Junus S, Asyraf MRM, Rajeshkumar L. Studies on tensile strength, fracture surface and biodegradation of biocomposite from polyvinyl alcohol (PVA) filled by sugarcane bagasse fiber. J Fiber Polym Compos 2023;2:46–55. https://doi.org/10.55043/jfpc.v2i1.75.
  18. Freitas PAV, Arias CILF, Torres-giner S, González-Martínez C, Chiralt A. Valorization of rice straw into cellulose microfibers for the reinforcement of thermoplastic corn starch films. Appl Sci 2021;11:8433. https://doi.org/10.3390/app11188433.
  19. Beniwal P, Toor A pal. Advancement in Tensile Properties of Polylactic Acid Composites Reinforced with Rice Straw Fibers. Ind Crop Prod 2023;192. https://doi.org/10.1016/j.indcrop.2022.116098.
  20. Malakar C, Ravivarman R. Biomass and bioenergy biodegradation and surface characteristic study of agro based bamboo / kenaf fiber reinforced PLA hybrid nano biocomposite. Biomass and Bioenergy 2026;209:109018. https://doi.org/10.1016/j.biombioe.2026.109018.
  21. Ostadi H, Hakimabadi SG, Nabavi F, Vossoughi M, Alemzadeh I. Enzymatic and soil burial degradation of corn starch / glycerol / sodium montmorillonite nanocomposites. Polym from Renew Resour 2020;11:15–29. https://doi.org/10.1177/2041247920952649.
